EHL 1004 N/NN

LOGITRANS® EHL scissor lift truck

The Logitrans® scissor lift truck EHL impresses with its quality, safety and effectiveness. It can be used to pick up pallets, transport them easily and conveniently or to load, unload or process material at the correct working height.

All of our scissor lift truck models can be used as a manual pallet truck, lifting table, supply table or workbench. < /span>

EFFECTIVENESS

• Quick lift function up to 200 kg
• Low height
• Working height can be adjusted
• Possibility of optional extras
• Optimum maneuverability
• Electric lifting
• The forks stop quickly and precisely
• Capacity 1500 kg to lift height 470 mm - Capacity 1000 kg from lift height 470 mm to 800 mm
• Safety supports guarantee a firm footing when the forks are raised (over 400 mm)
• Steering wheels optionally nylon (black) or polyurethane, fork rollers optionally tandem nylon (black) or tandem polyurethane
• Including maintenance-free battery 12 V / 70 Ah and built-in charger 12 V / 8 Ah

ERGONOMIC

• Ergonomically correct drawbar
• Individual settings
• Rounded corners
• Low weight

SECURITY

• Central arrangement of all operating functions
• Central arrangement of the emergency stop switch
• Low height
• Supports near the steering wheels

QUALITY

• Long service life
• Low maintenance costs
• Reliable construction of the cylinder
• Robust construction
• Use of quality materials
